Full semi trailers generally use inflatable solid tires, with low deck height and large loading capacity. There is no danger of puncture or blowout. It is safe, simple, and durable. It has no power and needs a tractor or forklift to tow. Usually, one or more flatbed trucks and a forklift or tractor form a train of vehicles to transport goods horizontally or carry large equipment.
The load of the full semi trailer is borne by itself, and it is only connected to the locomotive with a hook. The locomotive does not need to bear the trailer load but only provides power to help the trailer overcome the friction resistance of the road.
Application of full semi trailer
Full trailers are widely used in airports, ports, railway stations, factories, and large warehouses. It greatly improves the efficiency of cargo transfer and translation. Reduce the consumption cost of forklifts and manpower.
Specifications
| Main beam | The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8 mm material:Q345B |
| Side beam | Q235 16# channel steel |
| Axle | 13Ton, Fuwa brand option one hundred fifty thousand Kilometers no need maintenance |
| Tires | 12R22.5, 12 pcs. Taitong brand |
| Rim | 9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs |
| King pin | 2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster |
| Landing gear | 28 ton single action supporting legs |
| Steel spring | 10/10/10 leaf spring suspension |
| Air chamber | Six double air chamber |
Packaging and Transportation
In order to better ensure the safety of your goods, we will provide professional, environmentally friendly, convenient, and efficient packaging and transportation services.
Why choose us?
Chengda Group is a company engaged in the sales and service of semi-trailers, trucks, second-hand semi-trailers, second-hand trucks, auto parts, and new energy vehicles. Our professional technology and manufacturing experience can help your transportation be safer and more efficient. We can provide high-quality products and competitive prices.
Customer Cooperation
Our full semi trailers are widely exported to more than a dozen countries in Southeast Asia, America, the Middle East, and Africa, and have won a good reputation not only for their competitive products but also for their good credit and integrity.
